Condition: New
Place of Origin: Jiangsu, China (Mainland)
Model Number: DMQG-500*12
Voltage: 380V
Rated Power: 1.5 KW
Weight: 1500kg
Certification: ISO9001
After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 1 Year
Supply Ability: 1 Set/Sets per Month
Packaging Details Packed in plastic film then load into container
Port shanghai
Lead Time 30 daysPreviousNext

Feature:
Beams gantry welding structrue, overall good, high-strength steel, various guide surfaces are precision machined to endure the correct positioning of the moving body.

The end farmes driving four-wheel positioning,stable center of gravity to ensure good dynamic balance. All welded parts are used to the overall annealing to deal with stress, to prevent structural deformation.

The vertical rail track production of high-strength, the top surface and sides are made by precision maching of special grinde

Aspect to drive engagement, coupled with high-precision race and pinion imported precision planetary gearbox reducer, high output torque, low noise, long life lubrication characteristics, in order to achieve high-precision positioning drive. Accuracy level grinding teeth hardened(carburized quenching) shaft gear. The transmission mechanism is often life institutions.

Japan of Yaskawa imported servo drive system, smooth and reliable operation, high control accuracy.

Optional items:
The United States imports Hypertherm plasma power supply

Long rail

Specification

Show
10
entries
Edit
Model Cutting way Cutting diameter
(mm) Cutting wall thickness
(mm) Auxiliary long track
(m)
DMQG320*6 PLASMA Φ60-Φ320 1-6 6-12
DMQG500*12 PLASMA Φ60-Φ500 1-10 6-12
